Control Plane on AWS EKS (CloudFormation)

Overview

The Aurva Control Plane stores telemetry from Data Planes, runs analysis pipelines, and serves the Aurva console. This guide covers a self-hosted Control Plane deployment on Amazon EKS using the Aurva-provided CloudFormation templates plus Helm charts.

For the Terraform variant, see Control Plane on AWS EKS (Terraform).

Infrastructure Components

The CloudFormation stack provisions the same resources as the Terraform variant:

EKS

Component	Configuration
Architecture	x86_64
Node OS	Amazon EKS-Optimized Linux
Instance size	`c5a.xlarge` (varies with scale)
Storage	100 GB minimum

RDS (PostgreSQL)

Component	Configuration
Engine version	PostgreSQL 18
Instance class	`db.t4g.medium` (varies with scale)
Storage	128 GB minimum

OpenSearch

Component	Configuration
Engine version	OpenSearch 2.19
Instance class	`c7g.large.search` (varies with scale)
Nodes	3 minimum
Volume	Sized based on QPS

Storage

Bucket	Configuration
Alerts & Reports	Standard, lifetime retention
OpenSearch snapshots	Glacier (first 120 days), then Deep Archive

All buckets use SSE-S3 encryption, block public access, and restrict access to the Control Plane IAM role.

Networking & IAM

Component	Notes
Load balancers	1 ALB and 1 NLB
IAM	Read/write/delete for S3 and OpenSearch (managed by the stack)

Deployment Prerequisites

VPC

A VPC with at least 2 private subnets.
Each subnet must have at least 96 available IPv4 addresses.

ACM Certificate

An ACM certificate matching your company domain (e.g. *.aurva.com) must already exist in the AWS account. The stack attaches it to the load balancers.

Jump Server

A Linux jump server inside the same VPC, with the following CLIs installed:

CLI	Verify
AWS CLI	`aws --version`
Helm	`helm version`
kubectl	`kubectl version`
curl	`curl --version`

Networking Prerequisites

Source	Destination	Port	Purpose
VPC	`resources.deployment.aurva.io`	443	Download deployment scripts and resources
VPC	`bifrost.aurva.io`	443	License validation

Deployment Workflow

The deployment is split into two phases: infrastructure (CloudFormation) and application (Helm).

Infrastructure — Step 1: Download the bundle

mkdir -p /opt/aurva-controlplane
cd /opt/aurva-controlplane
curl -O https://resources.deployment.aurva.io/manifests/main/install-controlplane-aws-kube-cfn.tar.gz
tar -xzvf install-controlplane-aws-kube-cfn.tar.gz

After extraction:

install-controlplane-aws-kube-cfn/
├── cloudformation/
└── helm/

Infrastructure — Step 2: Configure stack parameters

cd install-controlplane-aws-kube-cfn/cloudformation
cp parameters.json.example parameters.json
vi parameters.json

Key parameters:

Parameter	Description	Example
`VpcId`	Existing VPC ID	`vpc-0c1e176679c6f5778`
`PrivateSubnetIds`	Comma-separated private subnet IDs	`subnet-02b70317d0fa1b5d7,subnet-06aa8777e1dab9cb8`
`PublicSubnetIds`	Comma-separated public subnet IDs	`subnet-03c901a039a89e31b,subnet-0fcdac58aeef4329e`
`AcmCertificateArn`	ARN of the ACM certificate	`arn:aws:acm:ap-south-1:...:certificate/...`
`EksNodeInstanceType`	EKS node group instance type	`c5a.xlarge`
`RdsInstanceClass`	RDS instance class	`db.t4g.medium`
`RdsStorageSize`	RDS allocated storage (GB)	`256`
`OsInstanceType`	OpenSearch instance type	`c7g.large.search`
`OsNodeCount`	OpenSearch data node count	`3`
`OsVolumeSize`	OpenSearch EBS volume size (GB)	`100`

Infrastructure — Step 3: Deploy the CloudFormation stack

aws cloudformation create-stack \
  --stack-name aurva-controlplane \
  --template-body file://template.yaml \
  --parameters file://parameters.json \
  --capabilities CAPABILITY_NAMED_IAM \
  --region ap-south-1

# Wait for completion
aws cloudformation wait stack-create-complete \
  --stack-name aurva-controlplane \
  --region ap-south-1

Stack creation typically takes 15–25 minutes.

Infrastructure — Step 4: Get stack outputs

aws cloudformation describe-stacks \
  --stack-name aurva-controlplane \
  --query 'Stacks[0].Outputs' \
  --output table \
  --region ap-south-1

Application — Step 1: Export Helm values

The stack outputs include a Helm values snippet:

aws cloudformation describe-stacks \
  --stack-name aurva-controlplane \
  --query "Stacks[0].Outputs[?OutputKey=='HelmValuesSnippet'].OutputValue" \
  --output text \
  --region ap-south-1 > ../helm/env/production.yaml

Application — Step 2: Set the Kubernetes context

aws eks update-kubeconfig \
  --name $(aws cloudformation describe-stacks \
    --stack-name aurva-controlplane \
    --query "Stacks[0].Outputs[?OutputKey=='ClusterName'].OutputValue" \
    --output text --region ap-south-1) \
  --region ap-south-1

Application — Step 3: Install the Helm chart

cd ../helm
helm upgrade --install aurva-controlplane . \
  -f values.yaml \
  -f env/production.yaml \
  -n aurva-controlplane \
  --create-namespace

Verification

kubectl -n aurva-controlplane get pods

All pods should reach Running. Once the load balancers are healthy, the Aurva console becomes reachable at the configured domain.

Updating the Stack

aws cloudformation update-stack \
  --stack-name aurva-controlplane \
  --template-body file://template.yaml \
  --parameters file://parameters.json \
  --capabilities CAPABILITY_NAMED_IAM \
  --region ap-south-1

Next Steps

Deploy a Data Plane to start collecting telemetry.
Configure Monitoring for your first data asset.
